The GRACO 19D155 SoloTech™ h16 Peristaltic Pump is a robust, hygienic pump designed for metering and transferring challenging fluids such as flavorants, colorants, solids, abrasives, and slurries. It features a single roller design that compresses an engineered FDA Nitrile hose through a full 360 degrees of rotation, with a 316 stainless steel (SST) sanitary clamp barb for easy cleaning and maintenance. This pump is intended for use in food, beverage, and personal care industries where only the hose contacts the fluid, ensuring product purity and reducing contamination risk.

Key Features:

• Peristaltic Hose Pump
• SoloTech™ h16
• Powder-coated aluminum housing, FDA Nitrile hose, 316 SST sanitary clamp barb
• Maximum fluid pressure: 125 psi (for similar models; confirm for 19D155)
• Designed for metering and dosing flavorants, colorants, solids, abrasives, and slurries in food, beverage, and personal care applications
• FDA Compliant Materials, EC 1935/2004, CE (for similar models; confirm for 19D155)
• Single roller design for longer hose life and reduced maintenance
• No valves, seals, or glands—inexpensive to maintain
• Reversible operation for emptying lines or clearing blockages
• Easy-to-install and remove hose barb assembly—no special tools required
• Removable powder-coated aluminum cover with large sight window for easy access
• Lightweight housing with adjustable feet for flexible mounting
• Optional leak detector kit available

Applications:
Ideal for metering and dosing flavorants, colorants, solids, abrasives, and slurries in food, beverage, and personal care manufacturing. Suitable for applications requiring hygienic transfer of sensitive or abrasive materials.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, reliability, and compliance with industry standards.
• Ensure proper alignment and secure mounting using adjustable feet
• Install the hose barb assembly without special tools for quick setup
• Regularly inspect the hose for wear and replace as needed to maintain performance and hygiene
• Use the removable cover for easy access during maintenance
• Consider installing the optional leak detector kit for added safety
