The GRACO 205626 is a robust, high-volume oil pump designed for industrial applications. It is constructed primarily from aluminum and is intended for pumping non-corrosive and non-abrasive oils and lubricants such as motor oil, gear lube, and automatic transmission fluid (ATF). This pump is engineered for demanding, high-volume fluid transfer tasks within GRACO equipment and compatible systems.

Key Features:

• Oil Pump
• Fire-Ball® 425 Series, 10:1 Universal Size
• Aluminum
• 12 GPM (approximate free flow rate at 100 PSI)
• 540 PSI Max Fluid Working Pressure
• Petroleum- and synthetic-based oils (motor, gear, and ATF)
• Large 4.25 inch (107.9 mm) air motor for high power and long pipe runs
• Designed for efficiency, reliability, and longevity
• Suitable for high-volume, demanding applications
• Ease of maintenance and robust construction

Applications:
Ideal for truck fleet service, industrial lubrication, and high-volume oil transfer in mining, agriculture, and other heavy-duty environments.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, safety, and longevity of the equipment.
• Ensure all connections are secure and use appropriate torque settings (e.g., 30–40 ft.-lbs for some components, 45–55 ft.-lbs for others)
• Do not reuse old lock wires; replace with new ones during maintenance
• Follow all safety instructions and warnings in the manual
• Use the piston assembly tool included in Repair Kit 238751 for fluid cylinder assembly
• Regularly inspect and replace worn components
• Use only compatible, non-corrosive, and non-abrasive fluids
• Save and consult the equipment manual for detailed maintenance procedures
