The GRACO 233057 Husky 716 is a stainless steel air-operated double diaphragm (AODD) pump package designed for transferring fluids from 55-gallon (208-liter) drums. It features stainless steel seats, PTFE balls, PTFE diaphragms, and a stainless steel tube, making it suitable for handling a wide range of industrial fluids with high reliability and minimal maintenance.

Key Features:

• Air-Operated Double Diaphragm (AODD) Pump
• Husky 716, 3/4 inch (19.05 mm) porting
• Stainless steel body, SS seats, PTFE balls, PTFE diaphragms, SS tube
• 14 GPM (53 LPM) typical, up to 16 GPM (61 LPM) maximum free flow
• 100 psi (7 bar, 0.7 MPa) maximum
• Designed for use with 55-gallon (208-liter) drums; suitable for a wide range of industrial fluids
• No mechanical seals to leak or fail
• Quiet operation (less than 85 dBa, can be reduced further with remote muffler)
• Easy-to-service air valve and ball checks
• External controller for remote control capabilities
• Engineered for heavy-duty, lasting performance
• Center- and end-porting options

Applications:
Ideal for transferring fluids in industrial, mining, agricultural, and maintenance environments where reliability, ease of maintenance, and compatibility with aggressive or corrosive fluids are required.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, longevity, and safety of the equipment. Non-genuine parts may compromise reliability and void warranties.
• Ensure proper alignment and secure mounting of the pump and suction tube
• Use appropriate fittings and hoses for the intended fluid and pressure
• Regularly inspect and maintain diaphragms, balls, and air valve for optimal performance
• Follow GRACO’s recommended maintenance schedule and procedures
• Consult the product manual for specific installation and maintenance instructions
