The GRACO G24B05 is a bellows piston pump designed for reliable, low-maintenance operation in demanding industrial environments. Constructed from 300 series stainless steel, it is intended for use with shear-sensitive, abrasive, catalyzed, solvent, waterborne, and moisture-sensitive materials, as well as UV-cure coatings. The pump features a V-packing seal for enhanced durability and is cart-mounted for ease of use and installation.

Key Features:

• Bellows piston pump
• G24B05, 24:1 ratio, 150 cc pump volume per cycle
• 300 series stainless steel
• Maximum fluid outlet pressure: 2400 psi (165 bar); Maximum air inlet pressure: 100 psi (7 bar)
• Catalyzed coatings, abrasive materials, solvent and waterborne materials, moisture-sensitive materials, UV-cure coatings
• No seals exposed to the atmosphere for low maintenance and high reliability
• Easy-to-flush lower design for fast color changes and reduced material waste
• V-packing seal for handling abrasive materials
• Cart-mount configuration for operator-friendly access
• Quick removal coupler for easy disassembly and serviceability
• Reliable air valve for smooth and rapid changeover
• Inlet fitting can be rotated 360 degrees for easy access

Applications:
Ideal for industrial environments requiring reliable, low-maintenance pumps for handling shear-sensitive, abrasive, or moisture-sensitive materials, including UV coatings and waterborne materials. Suitable for use in paint kitchens, circulation supply systems, and other applications where material integrity and minimal downtime are critical.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, reliability, and compatibility with existing equipment, reducing the risk of downtime and material waste.
• Ensure the pump is mounted securely on the cart for stability and operator safety
• Connect all hoses and fittings according to the manufacturer’s instructions
• Verify that the air supply is clean and regulated to the recommended pressure
• Regularly inspect and maintain seals and fittings to prevent leaks and ensure long service life
• Follow GRACO’s recommended maintenance schedule for best results
