The GRACO CD1231 is a compact, electric automatic lubrication pump designed for dispensing oil or grease up to NLGI #2. It features a 35 lb (approximately 16 kg) bucket, vent-valve pump, lifting handle, and integrated pressure and low-level switches. This unit is constructed for robust, reliable operation in demanding environments such as heavy-duty earth-moving machinery and off-road equipment.

Key Features:

• Automatic lubrication pump (oil or grease)
• Compact Dyna-Star® 24 VDC, 35 lb bucket
• Durable, compact design with integrated lifting handle and vent-valve pump
• Oil and grease up to NLGI #2; compatible with heavy-duty earth-moving and off-road equipment
• Compact footprint for easy installation
• Integrated lifting handle for portability
• Vent-valve pump for reliable operation
• Pressure and low-level switches for monitoring and safety
• Robust, reliable construction for harsh environments
• Easy maintenance and serviceability

Applications:
Designed for use in heavy-duty earth-moving machines (dozers, graders, wheel loaders, haul trucks, excavators, etc.) and off-road equipment in extreme work environments. Suitable for in-plant machinery requiring reliable, automatic lubrication.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, reliability, and safety. Non-genuine parts may compromise system integrity and void warranties.
• Ensure the pump is mounted securely in a location that allows easy access for maintenance and monitoring
• Connect the pump to a 24 VDC power source as specified
• Use compatible oil or grease up to NLGI #2
• Regularly check pressure and low-level switches for proper operation
• Follow all safety guidelines and local regulations during installation and maintenance
• Regularly inspect and maintain the pump and associated components
• Monitor system alerts from pressure and low-level switches
• Keep the area around the pump clean and free from debris
• Consult the equipment manual for detailed installation and maintenance procedures
