The GRACO 24B478 is a stainless steel modular divider valve designed for precise lubrication distribution in demanding environments. It is intended for use with oil and grease in on-road vehicles, off-road equipment, and in-plant machinery.

Key Features:

• Divider Valve
• MSP-35S-SS
• Stainless Steel (303 material)
• Discharge per piston stroke: 0.070 in³ (1.15 cm³)
• Maximum working pressure: 3500 psi (241 bar); Minimum working pressure: 200 psi (14 bar)
• Oil, Grease (Maximum NLGI Grade #2)
• Highly durable for harsh environments (e.g., salty air, repetitive cleaning)
• Proven design for reliability and long service life
• No cycle indicator
• Maximum cycle rate: 200 cycles/min
• Maximum operating temperature: 350°F (176°C)

Applications:
On-road vehicles, off-road equipment, in-plant machinery, food and beverage, offshore wind and oil rigs, marine, lift cranes, locks and dams, pulp and paper production, chemical processing, oil and gas applications

Installation Notes:

• Using genuine GRACO parts ensures compatibility, reliability, and optimal performance of the lubrication system.
• Ensure proper alignment and secure mounting of the valve
• Use compatible lubricants as specified (oil or grease, NLGI Grade #2 maximum)
• Follow manufacturer guidelines for pressure and temperature limits
• Regularly inspect for leaks or wear, especially in harsh environments
• For modular systems, order working sections in multiples of five as required
• Periodically check for proper operation and feedback from the system
• Clean and inspect valve components during routine maintenance
• Replace worn or damaged parts with genuine GRACO components
