The GRACO 24B482 is a stainless steel modular divider valve designed for precise lubrication distribution in demanding environments. It is constructed from durable 303 stainless steel and is intended for use in automatic lubrication systems for on-road vehicles, off-road equipment, and in-plant machinery. The valve ensures accurate delivery of oil or grease to multiple lubrication points.

Key Features:

• Divider Valve
• MSP-30T-SS, 0.030 in³ (0.49 cm³) discharge per piston stroke
• Stainless Steel (303)
• Minimum: 200 psi (14 bar); Maximum: 3,500 psi (241 bar, 24,100 kPa)
• Oil, Grease (Maximum NLGI Grade #2)
• Modular design allows quick change of valve sections without disturbing lube lines
• Built-in outlet check valves for accurate lube delivery
• Durable 303 stainless steel for harsh environments (salty air, repetitive cleaning)
• No cycle indicator (optional accessories available)
• Maximum cycle rate: 200 cycles/min
• Maximum operating temperature: 350°F (176°C)

Applications:
On-road vehicles, off-road equipment, in-plant machinery, food and beverage, off-shore wind and oil rigs, marine, lift cranes, locks and dams, pulp and paper production, chemical processing, oil and gas applications

Installation Notes:

• Using genuine GRACO parts ensures compatibility, reliability, and optimal performance of the lubrication system.
• Ensure proper alignment and secure mounting of the valve
• Use compatible oil or grease (maximum NLGI Grade #2)
• Follow manufacturer guidelines for pressure and temperature limits
• Consider using optional accessories such as magnetic or electronic proximity switch cycle indicators for troubleshooting and maintenance
• Quick change valve sections can be removed from the base assembly without disturbing lube lines, minimizing downtime
• Regularly inspect for leaks or blockages
• Clean valve and surrounding area to prevent contamination
• Replace worn or damaged sections promptly
