The GRACO 24N385 is a stainless steel base plate assembly for the Trabon® MSP modular divider valve system, designed to distribute lubricant to multiple points in automated lubrication systems. It is constructed from stainless steel for corrosion resistance and is intended for use in demanding industrial environments.

Key Features:

• Divider Valve Base Plate Assembly
• MSP, 6 Section, NPSF
• Stainless Steel
• Up to 3,500 psi (241 bar) for MSP modular divider valves
• Compatible with Trabon® MSP modular divider valve systems; suitable for oil or grease up to NLGI #2
• Modular, stackable design for flexible installation
• Corrosion-resistant stainless steel construction
• Fluoroelastomer (FKM) o-ring seals for leak prevention
• Built-in check valves to prevent lube re-entry and keep lines full
• Field-installable crossport or singling plates for increased flow or odd-numbered lube points
• Bypass section available for future expansion or to eliminate a piston section

Applications:
Used in centralized lubrication systems for industrial machinery, mining, agriculture, and other sectors requiring reliable, multi-point lubrication.

Installation Notes:

• Using genuine GRACO parts ensures compatibility, reliability, and optimal performance of the lubrication system.
• Ensure all components are clean and free of debris before assembly
• Follow torque specifications for all fasteners and plugs
• Use appropriate tools for installation to avoid damage to stainless steel components
• Verify compatibility with existing MSP modular divider valve sections and inlet/outlet connections
• Consult the GRACO manual for detailed assembly and maintenance procedures
