The GRACO 557769 Trabon® MXP Divider Valve is a modular manifold proportioning device designed for oil and grease lubrication systems. It is constructed from zinc-plated steel and is intended for use within GRACO lubrication equipment to distribute lubricant to multiple points efficiently.

Key Features:

• Divider Valve
• 6 Section Tie Rod (3 required per assembly)
• Zinc-plated steel
• Maximum 3,000 psi (207 bar)
• Oil or grease lubrication systems
• Modular design allows for up to 10 subplates and valve sections, serving up to 20 lubrication points
• High reliability and ease of maintenance
• Maximum operating temperature: 350°F (177°C)
• Maximum cycle rate with cycle pin: 60 CPM
• Maximum cycle rate without cycle pin or with proximity switch: 200 CPM
• Net weight (6 section assembly): 31 lbs. 3 oz (14.2 kg)

Applications:
Used in in-plant machinery and industrial lubrication systems to ensure precise and reliable distribution of oil or grease to multiple lubrication points.

Installation Notes:

• Using genuine GRACO parts ensures compatibility, reliability, and optimal performance of the lubrication system.
• Ensure all tie rod nuts are torqued to 6–9 ft. lbs
• Enclosure plugs should be torqued to 48 ± 2 ft. lbs
• Indicator plug torque: 12–15 ft. lbs
• Valve section mounting screw torque: 12–13 ft. lbs
• Follow manufacturer guidelines for assembly and maintenance to prevent leaks and ensure long service life
