The GS35 Plug-Free™ Hot Melt Applicator is a high-performance adhesive dispensing device designed for case and carton sealing. It is constructed from materials such as aluminum, brass, carbide, carbon steel, and stainless steel, and is engineered for reliable, plug-free operation in demanding industrial environments.

Key Features:

• Hot Melt Applicator
• GS35 Plug-Free™ with 4 Modules
• Aluminum, Brass, Carbide, Carbon Steel, Stainless Steel
• Maximum Working Fluid Pressure: 1500 psi (103 bar, 10.3 MPa); Operating Pneumatic Pressure Range: 40–80 psi (2.8–5.5 bar, 0.28–0.55 MPa)
• Designed for use with InvisiPac hot melt adhesive systems
• UL499, CSA88, CE, ISO 9001
• Innovative free-flow manifold design eliminates nozzle plugs
• Integrated applicator filtering protects ball and seat from debris and char
• Manifold filter in heated zone prevents cold spots and ensures consistent adhesive application
• Reaches operating temperature in less than 10 minutes
• Cycle time: greater than 3,500 cycles per minute
• Air open/spring close, ball and seat design
• Single, dual, quad, and custom module configurations available
• Compact and custom design options for various application needs

Applications:
Case and carton sealing, bonding, and sealing in packaging and manufacturing environments

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, reliability, and compatibility with existing systems, reducing downtime and maintenance costs.
• Ensure all connections are secure and free from leaks before operation
• Follow manufacturer guidelines for electrical and pneumatic connections
• Regularly inspect and replace filters to maintain plug-free operation
• Allow the manifold to reach operating temperature before use for consistent adhesive application
• Regularly check and clean filters to prevent debris and char buildup
• Monitor system for leaks and wear
• Use only recommended adhesives and consumables
• Schedule routine maintenance as per GRACO recommendations
