• Filtration Specifications: By-pass type filter unit with no internal media or element, designed specifically for testing purposes within fuel filtration systems.
• Fuel Compatibility: Suitable for use with Gasoline, Ethanol Blends up to 15%, Diesel, ULSD, and Biodiesel fuels, ensuring broad application across common fuel types.
• Flow Performance: Supports a flow rate up to 25 gallons per minute (GPM), equivalent to approximately 94.6 liters per minute (LPM), maintaining efficient fuel flow during operation.
• Pressure Ratings: Engineered to withstand typical dispenser system pressures; specific working and differential pressure ratings align with commercial fuel dispensing standards.
• Installation Details: Features a 1 1/2" - 16 UNF threaded connection for secure and compatible installation with standard dispenser filter housings.
• Physical Dimensions: Compact design with dimensions approximately 3.75 inches in diameter and 5.31 inches in length, facilitating easy integration into existing fuel systems.
• Quality Certifications: Manufactured by Cim-Tek in the USA, adhering to stringent quality control standards; UL listing status applies to related series products.
• Adapter Compatibility: Compatible with standard Cim-Tek adapters and housings designed for the 400 Series, enabling flexible system configurations.
• Application Scope: Ideal for commercial and industrial fuel dispensing systems requiring by-pass filtration for testing and maintenance; excludes aviation fuel applications.

This Cim-Tek 400 Series By-Pass Fuel Filter unit (Model 400 Series) offers a reliable, no-media solution for testing fuel filtration systems across a variety of fuel types. Its robust construction and compatibility with common dispenser fittings make it an essential component for maintaining fuel quality and system integrity in commercial environments.
