The GRACO 24B481 is a stainless steel modular divider valve designed for precise lubrication distribution in automated systems. It is intended for use with oil or grease in on-road vehicles, off-road equipment, and in-plant machinery.

Key Features:

• Divider Valve
• MSP-25T-SS, 0.025 in³ (0.41 cm³) discharge per piston stroke
• Stainless Steel
• Discharge per piston stroke: 0.025 in³ (0.41 cm³)
• Maximum working pressure: 3500 psi (241 bar, 24100 kPa); Minimum working pressure: 200 psi (14 bar)
• Oil, Grease (Maximum NLGI Grade #2)
• Modular design for easy maintenance and quick change of valve sections without disturbing lube lines
• High reliability and industry-standard quality
• Maximum cycle rate: 200 cycles/min
• Maximum operating temperature: 350°F (176°C)
• Built-in outlet check valves for accurate lube delivery
• Optional performance indicators and cycle indicators available

Applications:
On-road vehicles, off-road equipment, in-plant machinery

Installation Notes:

• Using genuine GRACO parts ensures compatibility, reliability, and optimal performance of the lubrication system.
• Ensure proper alignment and secure mounting of the valve assembly
• Use compatible oil or grease as specified
• Regularly inspect for leaks and proper operation
• Consider using optional cycle indicators for monitoring lube events
• Follow manufacturer guidelines for maintenance intervals
