The GRACO 287030 CleanShot Valve is a pressure-actuated shut-off valve designed for airless paint spray guns. It is constructed for durability and is intended to provide a clean, spatter-free spray pattern by shutting off fluid at the tip. The valve is commonly used in professional painting and coating applications.

Key Features:

• Shut-Off Valve
• CleanShot, 7/8" outlet thread
• Minimum operating pressure: 700 psi (4.8 MPa, 48 bar); Maximum working pressure: 3600 psi (24.8 MPa)
• All GRACO 7/8" thread airless spray guns and extensions, including Contractor, Contractor II, FTx, SG1, SG2, SG3 Magnum, In-Line Valve, tip extensions, heavy-duty and pole-gun extensions. Also works with most other brands of airless sprayer guns and extensions with 7/8" threads.
• Unique needle valve shuts fluid off at the tip for a clean pattern – no spitting
• 180° tip swivel provides versatility when spraying walls and ceilings
• Pressure-actuated operation
• Includes RAC X Guard and LTX517 tip
• Gasket included

Applications:
Professional painting and coating applications, including walls, ceilings, and other surfaces requiring a clean, spatter-free finish. Suitable for use with airless spray guns and extensions in various industrial and commercial settings.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, safety, and compatibility with GRACO equipment.
• Ensure the spray gun and extension are compatible with 7/8" thread size
• Follow manufacturer guidelines for installation and maintenance
• Check all connections for leaks before operation
• Replace gasket if damaged or worn
