The GRACO B-510-22 is a replacement nozzle, chute, and chopper assembly designed for use with the GRACO B-510 fiberglass chopper. It is typically constructed from durable materials suitable for handling fiberglass and resin mixtures. Its primary function is to guide and control the flow of chopped fiberglass and resin during spray-up applications, ensuring proper mixing and application onto surfaces.

Key Features:

• Nozzle, Chute, Chopper Assembly
• B-510-22
• GRACO B-510 Fiberglass Chopper
• Facilitates precise control of fiberglass and resin mixture
• Allows for adjustment of glass angle and dispersion
• Designed for reliable performance in demanding spray-up environments
• Ease of maintenance and replacement

Applications:
Used in fiberglass spray-up applications for industries such as marine, automotive, and construction, where composite materials are applied to molds or surfaces.

Installation Notes:

• Using genuine GRACO parts ensures optimal performance, safety, and compatibility with GRACO equipment.
• Ensure the chopper is powered off and depressurized before installation
• Align the chute and nozzle assembly according to the equipment manual
• Adjust the chute for optimal glass angle and dispersion as described in the manual
• Regularly inspect and clean the assembly to prevent clogging and ensure consistent performance
• Periodically check for wear and replace as needed
• Keep the assembly clean to avoid buildup of resin or fiberglass
• Follow GRACO’s recommended maintenance schedule
